| SPECIFICATIONS |
| Brand | Dell |
| Series | Thunderbolt USB Type-C Docks |
| Model | Pro Thunderbolt 4 130W Dock (210-BTHY / WD25TB4) |
| Connectivity |
| Upstream Port | 1x Thunderbolt 4 USB Type-C Connector (DisplayPort 1.4, 96W - 130W Power Delivery) |
| Downstream Ports | 2x Thunderbolt 4 USB Type-C Ports (DisplayPort 1.4) |
| 1x USB 10Gbps Type-C Port (DisplayPort 2.1) |
| 1x USB 10Gbps Type-C Port |
| 4x USB 10Gbps Type-A Ports |
| 1x HDMI 2.1 Port (FRL) |
| 2x DisplayPort 1.4 Ports (DSC) |
| 1x Dell Power Port (Up to 180W Input) |
| 1x 2.5 Gigabit Ethernet RJ-45 Port |
| Power Source | AC Adapter, 180W (supplied in box) |
| Cable Length | 830mm, Integrated |
| Video Output (Host Supporting DSC) |
| HDMI | 1x HDMI 2.1 Port with FRL, supports up to 8K @ 60Hz, supports HDCP & HDR |
| DisplayPort | 2x DisplayPort 1.4 DSC Ports, supports up to 8K @ 60Hz, supports HDCP & HDR |
| Thunderbolt | 2x Thunderbolt 4 Ports with DisplayPort 1.4 DSC, supports up to 8K @ 60Hz, supports HDCP & HDR |
| 1x USB 10Gbps Type-C Port with DisplayPort 1.4 DSC, supports up to 8K @ 60Hz, supports HDCP & HDR |
| Setup Notes | Computers with Thunderbolt 3 ports may have lower maximum supported resolutions. Please consult your product manual and the Dell Thunderbolt 4 dock user's guide for support. |
| Computers with USB Type-C ports with DisplayPort, but not DSC, may have lower maximum supported resolutions. Please consult your product manual and the Dell Thunderbolt 4 dock user's guide for support. |
| Display Support (Host Supporting DSC) |
| Single Display | Up to 8K (7680x4320) @ 60Hz (HDMI, DisplayPort, Thunderbolt/USB-C) |
| Dual Displays | Up to 6K (6144x3456) @ 60Hz (HDMI, DisplayPort, Thunderbolt/USB-C) |
| Triple Display | Up to 3x 4K (3840x2160) @ 60Hz Monitors (HDMI, DisplayPort, Thunderbolt/USB-C) |
| Quad Display | Up to 4x 4K (3840x2160) @ 60Hz Monitors (HDMI, DisplayPort, Thunderbolt/USB-C) |
| Apple Multi-Display Support | Multi-Display support is possible on Macbook Air, Macbook Pro, Mac Mini, Mac Studio, iMac displays, but support may vary between Apple silicon versions and SKUs. |
| Multi-Display on Macbook Neo is not supported. |
| Setup Notes | To enable 8K (7680x4320) support, two DisplayPort 1.4 cables must be used to connect to the monitor. |
| Ethernet |
| Bandwidth | Gigabit Ethernet, Up to 2500 Mbps |
| Protocol Support | IPv4, IPv6, IEEE 802.3 |
| General |
| Dimensions | 205 x 90 x 35.3mm (D x W x H) |
| Weight | 0.567kg |
| Colour | Black |
| Software Management | Dell Firmware Utility |
| Dell Display and Peripheral Manager |
| Dell Command Update |
| Dell Device Management Console |
| Operating Systems Supported | Windows 10 |
| Windows 11 |
| Ubuntu 24.04 |
| Red Hat Enterprise Linux 9.7 |
| ChromeOS 141 |
| macOS |
| Remote Management Features | Intel AMT over Thunderbolt with select Intel vPro PCs |
| MAC Address Pass-through |
| PXE Boot |
| Dock Power Button Sync |
| Wake-on-LAN |
| WLAN to LAN Switch |
| Kernel Direct Memory Access (DMA) Protection |
| Dell Command Update (DCU) |
| Port Disablement |
| Host PC based firmware update |
| Firmware update on disconnect |
| Warranty Information |
| Warranty | 3 Year Limited Warranty |
