| SPECIFICATIONS | |
| Brand | InWin |
| Series | 515 Series |
| Model | 515 Black (IW-CS-515BLK-1AL120) |
| Physical Details | |
| Colour | Black |
| Materials | Steel |
| Tempered Glass | |
| Side Panel | Tempered Glass (side), fine mesh (top side panel) |
| Front I/O | 1x USB 20Gbps Type-C Port |
| 2x USB 5Gbps Type-A Ports | |
| 1x 3.5mm Combination Audio Jack | |
| 1x 3.5mm Microphone Audio Jack | |
| Motherboard Support | E-ATX (330mm), ATX, Micro-ATX, Mini-ITX |
| Expansion Slots | 7x Vertical PCI Slots |
| Drive Bays | 2x 2.5/3.5" Drive Bays (Behind motherboard tray) |
| 2x 2.5" Drive Bays (Mounted on motherboard tray) | |
| PSU Support | ATX |
| Dimensions | 515 x 225 x 502mm (D x H x W) |
| Weight | 11.38kg |
| Pre-Installed Fans | |
| Top | N/A |
| Front | N/A |
| Bottom | N/A |
| Rear | 1x Pre-Installed InWin Luna AL120 ARGB PWM 120mm Fan (Exhaust) |
| Fan Support | |
| Top | 3x 120mm fans |
| Front | 2x 120mm fans |
| Bottom | 3x 120mm fans |
| Rear | 1x 120mm |
| Radiator Support | |
| Top | 120, 240, 360mm support (405mm with tubes, 80mm thickness) |
| Front | 240mm support |
| Bottom | 120, 240, 360mm support (Requires removing GPU support bracket, 27mm thickness) |
| Rear | 120mm support |
| Clearance | |
| Motherboard Tray Width | Up to 330mm |
| CPU Cooler Height Limitation | Up to 170mm |
| GPU Length Limitation | Up to 385mm |
| PSU Length Limitation | Up to 200mm with cables |
| Cable Management | Yes, behind motherboard tray |
| General | |
| Dust Filters | Yes, bottom removable filter, mesh front & top panels |
| Chassis Lighting | Yes, InWin Logo is ARGB compatible with 3-pin 5V ARGB Headers |
| Warranty Information | |
| Warranty | 2 Year Limited Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
