| SPECIFICATIONS | |
| Brand | Cooler Master |
| Series | Elite Series |
| Model | Elite 502 ARGB (E502-KGNN-S00) |
| Physical Details | |
| Colour | Black |
| Materials | Aluminium |
| Plastic | |
| Steel | |
| Tempered Glass | |
| Panels | Tempered Glass (side), Front mesh, Full metal right side |
| Front I/O | 1x USB 5Gbps Type-C Port |
| 1x USB 5Gbps Type-A Port | |
| 1x 3.5mm Combination Audio Jack | |
| Motherboard Support | Supports E-ATX (277mm), ATX, Micro-ATX, Mini-ITX Motherboards |
| Supports Reverse Hidden Connector BTF Motherboards | |
| Expansion Slots | 7x Vertical PCI Slots |
| Supports vertical GPU mounts (sold separately) | |
| Drive Bays | 2x 3.5" Drive Bays (Removable) |
| Up to 6x 2.5" Drive Bays (2x behind motherboard, 3x side mount, 1x on PSU shroud) | |
| NOTE: 2x 2.5" bays behind motherboard may conflict with Micro-ATX BTF motherboards) | |
| PSU Support | ATX |
| Dimensions | 474 x 230 x 481mm (D x H x W) |
| Weight | 7.9kg |
| Pre-Installed Fans | |
| Top | N/A |
| Front | 3x Pre-Installed Cooler Master ARGB PWM 120mm Fans (Front Intake) |
| Bottom | N/A |
| Rear | N/A |
| Fan Support | |
| Top | 3x 120mm or 2x 140mm fans |
| Front | 3x 120mm or 3x 140mm fans |
| Bottom | N/A |
| Rear | 1x 120mm fan |
| Radiator Support | |
| Top | 120 / 140 / 240 / 280 / 360mm support |
| Front | 120 / 140 / 240 / 280 / 360 / 420mm (Limit: 457*140*27 mm) |
| Bottom | N/A |
| Rear | 120mm support |
| Clearance | |
| Motherboard Tray Width | 277mm (E-ATX) |
| CPU Cooler Height Limitation | Up to 170mm |
| GPU Length Limitation | Up to 360mm (with front radiator) |
| Up to 410mm (no front radiator) | |
| PSU Length Limitation | Up to 170mm (with HDD cage) |
| Up to 210mm (without HDD cage) | |
| Cable Management | Yes, 35mm behind motherboard tray |
| General | |
| Dust Filters | Yes, bottom, front & top removable filters |
| Chassis Lighting | Fans are ARGB PWM with a 3-pin 5V ARGB connector, attached to a splitter cable |
| Warranty Information | |
| Warranty | 2 Year Limited Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
