AMD 100-100000725WOF Ryzen Threadripper Pro 9955WX 5.40GHz 16-Core Zen 5 Socket sTR5 Desktop CPU - Cooler Not Included

More Views

Please note:
Images are for illustrative purposes only.

AMD 100-100000725WOF Ryzen Threadripper Pro 9955WX 5.40GHz 16-Core Zen 5 Socket sTR5 Desktop CPU - Cooler Not Included

Product ID: 51773

Special order item

Lead time before dispatch; 2 - 4 weeks from order

Be the first to review this product

- AMD Ryzen Threadripper Pro 9955WX
- Up to 5.4GHz Max Boost Clock
- 4.5GHz Base Clock
- 16 Cores, 32 Threads
- 1280KB L1 Cache
- 16MB L2 Cache
- 64MB L3 Cache
- AMD 4nm Zen 5 Architecture
- TSMC 6nm IO Die
- Requires Discrete Graphics Card
- 350W TDP
- Socket sTR5
- WRX90, TRX50, Pro 695 Chipsets Supported
- 8-Channel RDIMM DDR5 Memory
- Up to 6400 MT/s Supported
- 148 Total PCIe Lanes
- AMD Precision Boost 2 & PBO
- Unlocked for Overclocking
- AMD EXPO Memory Overclocking Technology
- Curve Optimizer Voltage Offsets
- AMD Memory Guard
- AMD Secure Processor
- Firmware TPM & Secure Boot
- Windows Device Guard
- VBS & Windows Secured-Core PC
- Supports Windows 11, Linux
- 3 Year Warranty

40 Products

- Please note: This CPU does not have integrated graphics, a discrete graphics card is required for video output.

Please note: pricing visible is already subject to a 2% discount applicable only to EFT payments.

R32,100.00

Qty:

Add to Wishlist

Product Description
Additional Information
Reviews (0)

Product Description

SPECIFICATIONS
Brand	AMD
Series	Ryzen Threadripper Pro 9000 WX Series
Model	Ryzen Threadripper Pro 9955WX (100-100000725WOF)
Form Factor	Desktops
AMD PRO Technologies	Yes
Former Codename	Shimada Peak
Processor Architecture	Zen 5
Number of CPU Cores	16
Multithreading (SMT)	Yes
Number of Threads	32
Max. Boost Clock	Up to 5.4 GHz
Base Clock	4.5 GHz
L1 Cache	1280 KB
L2 Cache	16 MB
L3 Cache	64 MB
Default TDP	350W
Processor Technology for CPU Cores	TSMC 4nm FinFET
Processor Technology for I/O Die	TSMC 6nm FinFET
Package Die Count	3
Unlocked for Overclocking	Yes
AMD EXPO Memory Overclocking Technology	Yes
Precision Boost Overdrive	Yes
Curve Optimizer Voltage Offsets	Yes
CPU Socket	sTR5
Supporting Chipsets	WRX90, TRX50, Pro 695
CPU Boost Technology	Precision Boost 2
Instruction Set	x86-64
Supported Extensions	AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX-plus, SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
Thermal Solution (PIB)	Not Included
Max. Operating Temperature (Tjmax)	95°C
*OS Support	Windows 11 - 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit, Windows 10 - 64-Bit Edition
Connectivity
Native USB 3.2 Gen 2 (10Gbps)	4
Native SATA Ports	4
PCI Express Version	PCIe 5.0
Native PCIe Lanes (Total/Usable/PCIe 5.0)	148, 144, 128
NVMe Support	Boot, RAID0, RAID1, RAID5, RAID10
System Memory Type	DDR5
Memory Channels	8
System Memory Subtype	RDIMM
System Memory Specification	Up to 6400 MT/s
ECC Support	Yes (Default Enabled)
Graphics Capabilities
Graphics Model	Discrete Graphics Card Required
Security, Virtualization, and Manageability
DASH support	Yes
AMD Memory Guard	Yes
AMD Secure Processor Support	Yes
Windows Secure Boot Support	Yes
UEFI Secure Boot Support	Yes
Windows Device Guard Support	Yes
Guest Mode Execution (GMET) Trap Support	Yes
Virtualization-Based Security (VBS) Support	Yes
Windows Secured-Core PC Support	Yes
Firmware TPM	Yes
AMD-V (SVM) Support	Yes
AMD-V Nested Paging (RVI) Support	Yes
AMD AVIC (Interrupt Virtualization) Support	Yes
AMD-Vi (I/O MMU Virtualization) Support	Yes
Second Level Address Translation (SLAT) Supported	Yes
Advanced Encryption Standard New Instructions (AES-NI)	Yes
AMD Enhanced Virus Protection (NX bit)	Yes
Key Features
Supported Technologies	AMD EXPO Technology
	AMD PRO technologies
	AMD Ryzen Technologies
Warranty Information
Warranty	3 Year Warranty
