| SPECIFICATIONS | |
| Brand | Antec |
| Series | FLUX Series |
| Model | FLUX Black (0-761345-10133-2) |
| Physical Details | |
| Colour | Black |
| Materials | Aluminium |
| Steel | |
| Tempered Glass | |
| Stained Walnut Solid Wood | |
| Side Panel | 4mm Tempered Glass (side), partial mesh (lower chamber, right side) |
| Front I/O | 1x USB 10Gbps Type-C Port (Front Panel) |
| 2x USB 5Gbps Type-A Ports (Front Panel) | |
| 1x 3.5mm Combination Audio Jack (Front Panel) | |
| Motherboard Support | Supports E-ATX (330mm), ATX, Micro-ATX, Mini-ITX Motherboards |
| Supports ATX & Micro-ATX Hidden Reverse Connector Motherboards | |
| Expansion Slots | 7x Vertical PCI Slots |
| Drive Bays | 1x 2.5"/3.5" Combo Drive Bay (Removable) |
| 1x 3.5" Drive Bay (Removable) | |
| 1x 2.5" Drive Bay (Behind Motherboard Tray) | |
| PSU Support | ATX |
| Dimensions | 484 x 239 x 502mm (D x W x H) |
| Weight | 9.27kg |
| Pre-Installed Fans | |
| Top | N/A |
| Front | 3x Pre-Installed Antec P12 PWM 120mm Fans (Front Intake) |
| PSU Shroud | 1x Pre-Installed Antec P12 Reverse PWM 120mm Fan (Bottom Intake) |
| Rear | 1x Pre-Installed Antec P14 PWM 140mm Fan (Rear Exhaust) |
| Fan Support | |
| Top | 3x 120mm or 2x 140mm fans |
| Front | 3x 120mm or 3x 140mm fans |
| PSU Shroud | 2x 120mm or 2x 140mm fans |
| Rear | 1x 120mm or 1x 140mm fan |
| Radiator Support | |
| Top | 120, 140, 240, 280, 360mm support |
| Front | 120, 140, 240, 280, 360, 420mm support |
| PSU Shroud | N/A |
| Rear | 120, 140mm support |
| Clearance | |
| Motherboard Tray Width | 330mm (may conflict with cable management grommets) |
| CPU Cooler Height Limitation | Up to 180mm |
| GPU Length Limitation | Up to 408mm |
| PSU Length Limitation | Up to 235mm with HDD cage |
| Cable Management | Yes, behind motherboard tray |
| General | |
| Dust Filters | Yes, bottom removable |
| Chassis Lighting | N/A, Includes 5-way ARGB & PWM Fan splitter hub |
| Warranty Information | |
| Warranty | 2 Year Limited Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
- Top notch - B, 13 May 2025
It's an amazing premium case with some of the best thermals out there.
A breeze to install in too. - Great Airflow - Charl, 29 January 2025
Very happy with this case. It comes pre-installed with five fans that are already wired to the fan hub. Its on the bigger side so there is no problem with fitting any components. The airflow is great and I can keep all my fans at a constant speed, keeping everything cool and quiet.
- Best Case at the moment - Jaun, 20 January 2025
i wanted originally the Antec flux Pro but was a little pricey at the moment so i took the next best thing the ordered this case and i was not disappointed the build Quality feels excellent for the price and to build into it was a breeze it was one of the easiest cases to build in very happy 10 out of 10
