| SPECIFICATIONS | |
| Brand | FSP |
| Series | Workstation Series |
| Model | U500 Workstation Tower (U500-B) |
| Physical Details | |
| Colour | Black |
| Materials | Aluminium |
| Steel | |
| Side Panel | Partial mesh metal side panels (left, right) |
| Front I/O | 1x USB 10Gbps Type-C Port |
| 2x USB 5Gbps Type-A Ports | |
| 1x 3.5mm Audio Jack | |
| Motherboard Support | EEB, CEB, E-ATX,ATX, M-ATX, Mini-ITX |
| Expansion Slots | 9x Vertical PCI Slots |
| Drive Bays | 4x 2.5"/3.5" Combo Drive Bays |
| 2x 2.5" Drive Bays | |
| PSU Support | ATX |
| Dimensions | 451 x 258 x 568mm (D x H x W) |
| Weight | 10.6kg |
| Pre-Installed Fans | |
| Top | N/A |
| Front | 4x FSP 120mm PWM Black Fans (Intake) |
| Side | N/A |
| Bottom | N/A |
| Rear | 1x FSP 120mm PWM Black Fan (Exhaust, with Digital Fan Speed Display) |
| Fan Support | |
| Top | 3x 120mm or 3x 140mm fans |
| Front | 4x 120mm or 3x 140mm fans |
| Side | N/A |
| Bottom | 3x 120mm fans (Conflicts with bottom HDD cage) |
| Rear | 1x 120mm or 1x 140mm fan |
| Radiator Support | |
| Top | 240 / 280 / 360mm support |
| Front | 240 / 280 / 360 / 420 / 480mm support (may conflict with HDD cage) |
| Side | N/A |
| Bottom | N/A |
| Rear | N/A |
| Clearance | |
| Motherboard Width Limit | N/A |
| CPU Cooler Height Limitation | Up to 180mm |
| GPU Length Limitation | Up to 420mm (With GPU Bracket) |
| PSU Length Limitation | Up to 250mm |
| Cable Management | Yes, cable depth behind motherboard tray |
| General | |
| Dust Filters | Yes, front removable filter, side & top panels with fine mesh |
| Chassis Lighting | N/A |
| Warranty Information | |
| Warranty | 1 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
