| SPECIFICATIONS |
| Brand | ASUS |
| Series | PRIME B760-PLUS D4 |
| Model | 90MB1CW0-M0EAY0 |
| CPU | Intel Socket LGA1700 for 13th Gen Intel Core & 12th Gen Intel Core, Pentium Gold and Celeron |
| Processors* |
| Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0** |
| * Refer to www.asus.com for CPU support list. |
| ** Intel Turbo Boost Max Technology 3.0 support depends on the CPU types. |
| Chipset | Intel B760 Chipset |
| Memory | 4 X DIMM, Max. 128GB, DDR4 5066(OC)/5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-Buffered Memory* |
| Dual Channel Memory Architecture |
| Supports Intel Extreme Memory Profile (XMP) |
| OptiMem |
| * Supported Memory Types, Data Rate (Speed), And Number Of DRAM Modules Vary Depending On The CPU And Memory Configuration, For More Information Please Refer To CPU/Memory Support List Under The Support Tab Of Product Information Site Or Visit Https://www.asus.com/support/. |
| Graphics | 1 X DisplayPort** |
| 1 X VGA Port |
| 1 X HDMI Port*** |
| * Graphics Specifications May Vary Between CPU Types. Please Refer To www.intel.com For Any Updates. |
| ** Supports Max. 4K@60Hz As Specified In DisplayPort 1.4. |
| *** Supports 4K@60Hz As Specified In HDMI 2.1. |
| Expansion Slots | Intel 13th & 12th Gen Processors* |
| 1x PCIe 5.0 X16 Slot |
| Intel B760 Chipset |
| 1x PCIe 4.0 X16 Slot (Supports X4 Mode) |
| 2x PCIe 3.0 X1 Slots |
| Note: To Ensure Compatibility Of The Device Installed, Please Refer To https://www.aasus.com/support/ For The List Of Supported Peripherals. |
| Storage | Total Supports 3x M.2 Slots And 4x SATA 6Gb/S Ports* |
| Intel 13th & 12th Gen Processors |
| M.2_1 Slot (Key M), Type 2242/2260/2280 (Supports PCIe 4.0 X4 Mode) |
| Intel B760 Chipset |
| M.2_2 Slot (Key M), Type 2242/2260/2280/22110 (Supports PCIe 4.0 X4 Mode) |
| M.2_3 Slot (Key M), Type 2242/2260/2280 (Supports PCIe 4.0 X2 Mode) |
| 4x SATA 6Gb/S Ports |
| * Intel Rapid Storage Technology Supports SATA RAID 0/1/5/10. |
| Ethernet | 1x Realtek 2.5Gb Ethernet |
| Wireless & Bluetooth | Vertical M.2 slot only (Key E, CNVi & PCIe)* |
| * Wi-Fi module is sold separately. |
| USB | Rear USB (Total 6 Ports) |
| 1x USB 3.2 Gen 2x2 Port (1 X USB Type-C) |
| 2x USB 3.2 Gen 2 Ports (2 X Type-A) |
| 1x USB 3.2 Gen 1 Port (1 X Type-A) |
| 2x USB 2.0 Ports (2 X Type-A) |
| Front USB (Total 7 Ports) |
| 1x USB 3.2 Gen 1 Connector (Supports USB Type-C) |
| 1x USB 3.2 Gen 1 Header Supports 2 Additional USB 3.2 Gen 1 Ports |
| 2x USB 2.0 Headers Support 4 Additional USB 2.0 Ports |
| Audio | Realtek 7.1 Surround Sound High Definition Audio CODEC* |
| - Supports: Jack-Detection, Multi-Streaming, Front Panel Jack-Retasking |
| - Supports Up To 24-Bit/192 KHz Playback |
| Audio Features | - Audio Shielding |
| - Premium Audio Capacitors |
| - Dedicated Audio PCB Layers |
| * A Chassis With An HD Audio Module In The Front Panel Is Required To Support 7.1 Surround Sound Audio Output. |
| Back Panel I/O Ports | 1x USB 3.2 Gen 2x2 Port (1x USB Type-C) |
| 2x USB 3.2 Gen 2 Ports (2x Type-A) |
| 1x USB 3.2 Gen 1 Port (1x Type-A) |
| 2x USB 2.0 Ports (2x Type-A) |
| 1x DisplayPort |
| 1x VGA Port |
| 1x HDMI Port |
| 1x Vertical M.2 Slot (Key E) |
| 1x Realtek 2.5Gb Ethernet Port |
| 3x Audio Jacks |
| Internal I/O Connectors | Fan and Cooling related |
| 1x 4-pin CPU Fan header |
| 1x 4-pin AIO Pump header |
| 3x 4-pin Chassis Fan headers |
| Power related |
| 1x 24-pin Main Power connector |
| 1x 8-pin 12V Power connector |
| Storage related |
| 3x M.2 slots (Key M) |
| 4x SATA 6Gb/s ports |
| USB |
| 1x USB 3.2 Gen 1 connector (supports USB Type-C ) |
| 1x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports |
| 2x USB 2.0 headers support 4 additional USB 2.0 ports |
| Miscellaneous |
| 3x Addressable Gen 2 headers |
| 1x Aura RGB header |
| 1x Clear CMOS header |
| 1x COM Port header |
| 1x Front Panel Audio header (AAFP) |
| 1x S/PDIF Out header |
| 1x SPI TPM header (14-1pin) |
| 1x 20-3 pin System Panel header with Chassis intrude function |
| 1x Thunderbolt (USB4) header |
| Special Features | ASUS 5X PROTECTION III |
| - DIGI VRM |
| - LANGuard |
| - Overvoltage Protection |
| - SafeSlot Core |
| - Stainless-Steel Back I/O |
| ASUS Q-Design |
| - Q-DIMM |
| - Q-LED Core |
| - Q-Slot |
| ASUS Thermal Solution |
| - M.2 Heatsink |
| - VRM Heatsink Design |
| ASUS EZ DIY |
| - ProCool |
| Aura Sync |
| - Aura RGB Header |
| - Addressable Gen 2 Headers |
| BIOS | 128 Mb Flash ROM |
| UEFI AMI BIOS |
| Operating System | Windows 11, Windows 10 64-bit |
| Form Factor | ATX Form Factor |
| 30.5 cm x 24.4 cm |
| Brand | ASUS |
| Series | PRIME B760-PLUS D4 |
| Model | 90MB1CW0-M0EAY0 |
| CPU | Intel Socket LGA1700 for 13th Gen Intel Core & 12th Gen Intel Core, Pentium Gold and Celeron |
| Processors* |
| Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0** |
| * Refer to www.asus.com for CPU support list. |
| ** Intel Turbo Boost Max Technology 3.0 support depends on the CPU types. |
| Chipset | Intel B760 Chipset |
| Memory | 4 X DIMM, Max. 128GB, DDR4 5066(OC)/5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-Buffered Memory* |
| Dual Channel Memory Architecture |
| Supports Intel Extreme Memory Profile (XMP) |
| OptiMem |
| * Supported Memory Types, Data Rate (Speed), And Number Of DRAM Modules Vary Depending On The CPU And Memory Configuration, For More Information Please Refer To CPU/Memory Support List Under The Support Tab Of Product Information Site Or Visit Https://www.asus.com/support/. |
| Graphics | 1 X DisplayPort** |
| 1 X VGA Port |
| 1 X HDMI Port*** |
| * Graphics Specifications May Vary Between CPU Types. Please Refer To www.intel.com For Any Updates. |
| ** Supports Max. 4K@60Hz As Specified In DisplayPort 1.4. |
| *** Supports 4K@60Hz As Specified In HDMI 2.1. |
| Expansion Slots | Intel 13th & 12th Gen Processors* |
| 1x PCIe 5.0 X16 Slot |
| Intel B760 Chipset |
| 1x PCIe 4.0 X16 Slot (Supports X4 Mode) |
| 2x PCIe 3.0 X1 Slots |
| Note: To Ensure Compatibility Of The Device Installed, Please Refer To https://www.aasus.com/support/ For The List Of Supported Peripherals. |
| Storage | Total Supports 3x M.2 Slots And 4x SATA 6Gb/S Ports* |
| Intel 13th & 12th Gen Processors |
| M.2_1 Slot (Key M), Type 2242/2260/2280 (Supports PCIe 4.0 X4 Mode) |
| Intel B760 Chipset |
| M.2_2 Slot (Key M), Type 2242/2260/2280/22110 (Supports PCIe 4.0 X4 Mode) |
| M.2_3 Slot (Key M), Type 2242/2260/2280 (Supports PCIe 4.0 X2 Mode) |
| 4x SATA 6Gb/S Ports |
| * Intel Rapid Storage Technology Supports SATA RAID 0/1/5/10. |
| Ethernet | 1x Realtek 2.5Gb Ethernet |
| Wireless & Bluetooth | Vertical M.2 slot only (Key E, CNVi & PCIe)* |
| * Wi-Fi module is sold separately. |
| USB | Rear USB (Total 6 Ports) |
| 1x USB 3.2 Gen 2x2 Port (1 X USB Type-C) |
| 2x USB 3.2 Gen 2 Ports (2 X Type-A) |
| 1x USB 3.2 Gen 1 Port (1 X Type-A) |
| 2x USB 2.0 Ports (2 X Type-A) |
| Front USB (Total 7 Ports) |
| 1x USB 3.2 Gen 1 Connector (Supports USB Type-C) |
| 1x USB 3.2 Gen 1 Header Supports 2 Additional USB 3.2 Gen 1 Ports |
| 2x USB 2.0 Headers Support 4 Additional USB 2.0 Ports |
| Audio | Realtek 7.1 Surround Sound High Definition Audio CODEC* |
| - Supports: Jack-Detection, Multi-Streaming, Front Panel Jack-Retasking |
| - Supports Up To 24-Bit/192 KHz Playback |
| Audio Features | - Audio Shielding |
| - Premium Audio Capacitors |
| - Dedicated Audio PCB Layers |
| * A Chassis With An HD Audio Module In The Front Panel Is Required To Support 7.1 Surround Sound Audio Output. |
| Back Panel I/O Ports | 1x USB 3.2 Gen 2x2 Port (1x USB Type-C) |
| 2x USB 3.2 Gen 2 Ports (2x Type-A) |
| 1x USB 3.2 Gen 1 Port (1x Type-A) |
| 2x USB 2.0 Ports (2x Type-A) |
| 1x DisplayPort |
| 1x VGA Port |
| 1x HDMI Port |
| 1x Vertical M.2 Slot (Key E) |
| 1x Realtek 2.5Gb Ethernet Port |
| 3x Audio Jacks |
| Internal I/O Connectors | Fan and Cooling related |
| 1x 4-pin CPU Fan header |
| 1x 4-pin AIO Pump header |
| 3x 4-pin Chassis Fan headers |
| Power related |
| 1x 24-pin Main Power connector |
| 1x 8-pin 12V Power connector |
| Storage related |
| 3x M.2 slots (Key M) |
| 4x SATA 6Gb/s ports |
| USB |
| 1x USB 3.2 Gen 1 connector (supports USB Type-C ) |
| 1x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports |
| 2x USB 2.0 headers support 4 additional USB 2.0 ports |
| Miscellaneous |
| 3x Addressable Gen 2 headers |
| 1x Aura RGB header |
| 1x Clear CMOS header |
| 1x COM Port header |
| 1x Front Panel Audio header (AAFP) |
| 1x S/PDIF Out header |
| 1x SPI TPM header (14-1pin) |
| 1x 20-3 pin System Panel header with Chassis intrude function |
| 1x Thunderbolt (USB4) header |
| Special Features | ASUS 5X PROTECTION III |
| - DIGI VRM |
| - LANGuard |
| - Overvoltage Protection |
| - SafeSlot Core |
| - Stainless-Steel Back I/O |
| ASUS Q-Design |
| - Q-DIMM |
| - Q-LED Core |
| - Q-Slot |
| ASUS Thermal Solution |
| - M.2 Heatsink |
| - VRM Heatsink Design |
| ASUS EZ DIY |
| - ProCool |
| Aura Sync |
| - Aura RGB Header |
| - Addressable Gen 2 Headers |
| BIOS | 128 Mb Flash ROM |
| UEFI AMI BIOS |
| Operating System | Windows 11, Windows 10 64-bit |
| Form Factor | ATX Form Factor |
| 30.5 cm x 24.4 cm |
| Warranty Information |
| Warranty | 3 Year Warranty |
