| SPECIFICATIONS | |
| Brand | AMD |
| Series | Ryzen 9 (Granite Ridge) |
| Model | 100-100001277WOF |
| Family | Ryzen |
| Series | Ryzen 9000 Series |
| Form Factor | Desktops, Boxed Processor |
| Market Segment | Enthusiast Desktop |
| AMD PRO Technologies | No |
| Architecture | Zen 5 |
| # of CPU Cores | 16 |
| Multithreading (SMT) | Yes |
| # of Threads | 32 |
| Max. Boost Clock | Up to 5.7 GHz |
| Base Clock | 4.3 GHz |
| L1 Cache | 1.28 MB |
| L2 Cache | 16 MB |
| L3 Cache | 64 MB |
| Default TDP | 170W |
| Processor Technology for CPU Cores | TSMC 4nm FinFET |
| Processor Technology for I/O Die | TSMC 6nm FinFET |
| Package Die Count | 3 |
| Unlocked for Overclocking | Yes |
| AMD EXPO Memory Overclocking Technology | Yes |
| Precision Boost Overdrive | Yes |
| Curve Optimizer Voltage Offsets | Yes |
| AMD Ryzen Master Support | Yes |
| CPU Socket | AM5 |
| Supporting Chipsets | A620, X670E, X670, B650E, B650, X870E, X870 |
| CPU Boost Technology | Precision Boost 2 |
| Instruction Set | x86-64 |
| Supported Extensions | AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX-plus, SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
| Thermal Solution (PIB) | Not Included |
| Recommended Cooler | Liquid cooler recommended for optimal performance |
| Max. Operating Temperature (Tjmax) | 95°C |
| *OS Support | Windows 11 - 64-Bit Edition, Windows 10 - 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit |
| Connectivity | Native USB 3.2 Gen 2 (10Gbps) Ports: 4, Native USB 2.0 (480Mbps) Ports: 1 |
| PCI Express Version | PCIe 5.0 |
| Native PCIe Lanes (Total/Usable) | 28, 24 |
| Additional Usable PCIe Lanes from Motherboard | X870E: 8x Gen4, X870: 4x Gen4, X670E: 12x Gen4, X670: 12x Gen4, B650E: 8x Gen4, B650: 8x Gen4 |
| NVMe Support | Boot, RAID0, RAID1, RAID5, RAID10 |
| System Memory Type | DDR5 |
| Memory Channels | 2 |
| Max. Memory | 192 GB |
| System Memory Subtype | UDIMM |
| Max Memory Speed | 2x1R DDR5-5600, 2x2R DDR5-5600, 4x1R DDR5-3600, 4x2R DDR5-3600 |
| ECC Support | Yes (Requires mobo support) |
| Graphics Capabilities | Graphics Model: AMD Radeon Graphics, Graphics Core Count: 2, Graphics Frequency: 2200 MHz |
| USB Type-C DisplayPort Alternate Mode | Yes |
| Warranty Information | |
| Warranty | 3 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
- Beast of CPU - Julian , 19 January 2026
Ive have this chip now for a few weeks. Upgraded from a Ryzen 9 3900. This chip is streets ahead of the old Zen 3 chip. Nearly twice the performance.
Runs a bit hot, but thats normal for such a high end chip. I typically run at about 65-70C during gaming (No Mans Sky). Around 80-85C for heavy software dev working like compiling. Air coolers are a no go here. You MUST have an AIO, and a pretty decent one at that. I have the Artic Freeze III unit, and it does a good job keeping the temp below 85C.
Very happy with my purchase. - Absolutely Amazing - Giovanni , 24 October 2025
Definitely working this puppy overtime, handling all the work I need to do with ease and at a better performance than what I had previously. Thank you wootware for the recommendation.
- **Review: AMD Ryzen 9 9950X** - Clinton, 18 July 2025
I recently purchased the AMD Ryzen 9 9950X and I’m extremely impressed. It’s incredibly quick and efficient, easily handling everything from gaming to heavy multitasking without breaking a sweat. The 16-core Zen 5 architecture really delivers top-tier performance, and I love how responsive my system feels. Just a note—there’s no cooler included, so you’ll need to get one separately. Overall, I’m very happy with this processor and highly recommend it!
- Multi Tasker - Hugo, 27 March 2025
In a Playback server. Why even think about anything else for this task? No problem with Arena, OBS and Alley running simultaneously.
