| SPECIFICATIONS | |
| Brand | ZOTAC |
| Series | Twin Edge Series |
| Model | ZT-B50620E-10M |
| Chipset | |
| GPU | GeForce RTX 5060 Ti |
| Chipset Manufacturer | NVIDIA |
| Interface | PCIe 5.0 x8 |
| Engine Clock | 2572 MHz |
| CUDA Cores | 4608 |
| GPU Architecture | NVIDIA Blackwell |
| Memory | |
| Effective Memory Clock | 28Gbps |
| Memory Size | 16GB |
| Memory Interface | 128-bit |
| Memory Type | GDDR7 |
| 3D API | |
| DirectX | Microsoft DirectX 12.1 Ultimate |
| OpenGL | OpenGL 4.6 |
| Vulkan | Vulkan 1.4 API |
| Connectivity | |
| Ports | 3x DisplayPort 2.1b with UHBR20 (up to 4K 480Hz or 8K 165Hz with DSC) |
| 1x HDMI 2.1b Connector (Supports 4K 120Hz HDR, 8K 60Hz HDR, and Variable Refresh Rate as specified in the HDMI 2.1b Specification) | |
| HDCP Support | v2.3 |
| Multi-Monitor Support | Quad Display |
| Maximum Digital Resolution | 7680 x 4320 |
| VR Ready | Yes |
| General | |
| SLI Support | N/A |
| Features | IceStorm 2.0 Cooling |
| Composite Heatpipe Combo | |
| Pass-through Airflow | |
| BladeLink Fans | |
| FREEZE Fan Stop | |
| VR Ready | |
| SFF-Ready Enthusiast GeForce Card | |
| 4th Gen Ray Tracing Cores | |
| 5th Gen Tensor Cores | |
| PCI Express Gen 5 | |
| Real-Time Ray Tracing Technology | |
| NVIDIA DLSS 4.0 with Frame Generation and Frame Warp | |
| NVIDIA GeForce Game Ready & Studio Drivers | |
| NVIDIA G-Sync Premium | |
| NVIDIA Reflex 2 | |
| NVIDIA Broadcast | |
| NVIDIA AV1 Encoder | |
| NVIDIA Omniverse 3D Design | |
| NVIDIA Canvas | |
| NVIDIA GPU Boost | |
| NVIDIA Encoder, 9th Generation | |
| NVIDIA Decoder, 6th Generation | |
| Power Requirements | |
| Recommended Power Supply | 650W |
| Power Consumption | 180W |
| Power Connector | 1x 8-Pin PCIe PEG Connector |
| Physical Aspects | |
| Form Factor | ATX |
| Slot Width | 2 Slot |
| Dimensions | 220.5mm x 120.25mm x 41.6mm |
| Warranty Information | |
| Warranty | 3 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
- Great! - Enzo, 14 January 2026
Got it for 10k just in time for the Vram prices to go way up, coming from a 3060ti trying to run 1440p/4k this is at least a easy double in performance. If you factor in frame gen (Which looks so convincing now with dlss 4.5 I cannot tell the difference between raw frame and ai) this scales even crazier. I am able to play cyberpunk path traced ultra settings at 1440p around 50 fps with dlss and 120 or so with frame gen and it feels great. Gonna use it for some local ai models as well to grow my business.
- Great so far - Kyle, 27 May 2025
Got this as an upgrade from my 1660 super, the difference is night and day.
Before I'd be struggling to hit 30 fps on some more intense games where I now have frames to spare.
I've only had the 5060 ti for a short time so this might change but I'm extremely happy with it right now.
Note: I'm only playing on 1080p but it is still fantastic so far
