| SPECIFICATIONS | |
| Brand | Antec |
| Series | CX Series |
| Model | CX500M ARGB (0-761345-10143-1) |
| Physical Details | |
| Colour | Black |
| Materials | Aluminium |
| Steel | |
| Tempered Glass | |
| Side Panel | 4mm Tempered Glass (front, side), partial mesh (right side) |
| Front I/O | 1x USB 10Gbps Type-C Port (Front Panel) |
| 2x USB 5Gbps Type-A Ports (Front Panel) | |
| 1x 3.5mm Combination Audio Jack (Front Panel) | |
| Motherboard Support | Micro-ATX, Mini-ITX |
| Expansion Slots | 5x Vertical PCI Slots |
| Drive Bays | 1x 2.5"/3.5" Combo Drive Bay (Removable) |
| 1x 3.5" Drive Bay (Removable) | |
| 1x 2.5" Drive Bay (Behind Motherboard Tray) | |
| PSU Support | ATX |
| Dimensions | 436 x 446 x 210mm (D x H x W) |
| Weight | 6.34kg |
| Pre-Installed Fans | |
| Side | 2x Pre-Installed Antec ARGB 120mm Fans (Intake) |
| Bottom | N/A |
| Rear | 1x Pre-Installed Antec ARGB 120mm Fan (Exhaust) |
| Fan Support | |
| Top | 3x 120mm or 2x 140mm fans |
| Side | 2x 120mm fans |
| PSU Shroud | 3x 120mm fans |
| Rear | 1x 120mm fan |
| Radiator Support | |
| Top | 120, 140, 240, 280, 360mm support |
| Side | N/A |
| PSU Shroud | N/A |
| Rear | N/A |
| Clearance | |
| Motherboard Tray Width | N/A |
| CPU Cooler Height Limitation | Up to 165mm |
| GPU Length Limitation | Up to 415mm |
| PSU Length Limitation | Up to 210mm with HDD cage |
| Up to 270mm without HDD cage | |
| Cable Management | Yes, 23mm depth behind motherboard tray |
| General | |
| Dust Filters | Yes, top & bottom removable |
| Chassis Lighting | Fans are Daisy-chained ARGB with SATA power |
| Supports all major motherboards and ARGB controllers | |
| Warranty Information | |
| Warranty | 1 Year Limited Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
