| SPECIFICATIONS | |
| Brand | Antec |
| Series | CX Series |
| Model | CX500M RGB |
| Physical Details | |
| Colour | White |
| Materials | Aluminium |
| Steel | |
| Tempered Glass | |
| Side Panel | 4mm Tempered Glass (front, side), partial mesh (right side) |
| Front I/O | 1x USB 5Gbps Type-C Port (Front Panel) |
| 2x USB 5Gbps Type-A Ports (Front Panel) | |
| 1x 3.5mm Combination Audio Jack (Front Panel) | |
| Motherboard Support | Micro-ATX, Mini-ITX |
| Expansion Slots | 5x Vertical PCI Slots |
| Drive Bays | 1x 2.5"/3.5" Combo Drive Bay (Removable) |
| 1x 3.5" Drive Bay (Removable) | |
| 1x 2.5" Drive Bay (Behind Motherboard Tray) | |
| PSU Support | ATX |
| Dimensions | 436 x 446 x 210mm (D x H x W) |
| Weight | 6.34kg |
| Pre-Installed Fans | |
| Side | 2x Pre-Installed Antec Fixed-Mode RGB 120mm Fans (Intake) |
| Bottom | N/A |
| Rear | 1x Pre-Installed Antec Fixed-Mode RGB 120mm Fan (Intake) |
| Fan Support | |
| Top | 3x 120mm or 2x 140mm fans |
| Side | 2x 120mm fans |
| PSU Shroud | 3x 120mm fans |
| Rear | 1x 120mm fan |
| Radiator Support | |
| Top | 120, 140, 240, 280, 360mm support |
| Side | N/A |
| PSU Shroud | N/A |
| Rear | N/A |
| Clearance | |
| Motherboard Tray Width | N/A |
| CPU Cooler Height Limitation | Up to 165mm |
| GPU Length Limitation | Up to 415mm |
| PSU Length Limitation | Up to 210mm with HDD cage |
| Up to 270mm without HDD cage | |
| Cable Management | Yes, 23mm depth behind motherboard tray |
| General | |
| Dust Filters | Yes, top & bottom removable |
| Chassis Lighting | Fans are fixed-mode RGB with Molex connectors |
| Warranty Information | |
| Warranty | 1 Year Warranty |
| Manufacturer's Site | Visit the manufacturer's website |
|---|---|
| Product Link | Visit the manufacturer's page for this product |
- Great case - Donovan, 26 May 2025
Pictures don't do this case justice, it is beautiful. The front IO is very conveniently placed, the glass pops off easy enough while remaining secure. Cable management was also nice. My only qualm is all the supplied fans (3) are exhausting air and if you turn them around the wires are visible. I will need to replace with reverse blade fans as adding 3 more fans to try balance doesn't make sense.
