HAVN HVN-CA-HS420-05 HS 420 Panoramic UniSheet Glass White SGCC Steel E-ATX Mid Tower Desktop Chassis

More Views

Please note:
Images are for illustrative purposes only.

HAVN HVN-CA-HS420-05 HS 420 Panoramic UniSheet Glass White SGCC Steel E-ATX Mid Tower Desktop Chassis

Product ID: 53557

In stock with Supplier

Lead time before dispatch; 2 - 5 business days

Be the first to review this product

- Mid-Tower Chassis
- Supports E-ATX, ATX, Micro-ATX, Mini-ITX Motherboards
- UniSheet Heat-formed Panoramic Front & Side Glass Panel
- Front, Top, Right & Rear-Mount Dust Filters
- Integrated Fan PWM Repeater Hub
- 2x USB 3.2 Gen 1 Type-A Ports, 1x USB 3.2 Gen 2 Type-C Port
- 1x Front-Panel 3.5mm Audio Jack
- 4x 3.5"/2.5" Combo HDD Drive Bays Supported
- 8x 2.5" HDD/SSD Drive Bays Supported
- Intuitive SimpliCable Routing System
- Supports Up to 11x 120mm Fans
- Radiator Support Up to 420mm
- CPU Cooler Clearance: 185mm
- GPU Cooler Clearance: 480mm
- PSU Length Clearance: 220mm
- Flexible Rubber Fan Vibration Isolators
- Internal Max 14" Display VESA Mounting
- Colour: White
- 2 Year Warranty

11 Products

Please note: pricing visible is already subject to a 2% discount applicable only to EFT payments.

R2,989.00

Qty:

Add to Wishlist

Product Description
Additional Information
Reviews (0)

Product Description

SPECIFICATIONS
Brand	HAVN
Series	HS 420 Series
Model	HS 420 (HVN-CA-HS420-05)
Physical Details
Colour	White
Materials	SGCC Steel Sheet Metal
Materials	ABS, Nylon, Silicon, Zinc alloy, NdFeB magnets
Side Panel	Tempered Glass
I/O Ports	1x USB 3.2 Gen 2 Type-C
	2x USB 3.2 Gen 1 Type-A
	1x Audio Jack
	1x Power & Reset Button
Motherboard Support	E-ATX (Max Width 277 mm) / ATX / M-ATX / Mini-ITX
Expansion Slots	6
Drive Bays	Right Fan Mount: 4 Storage Bays: 4 x 3.5'' / 8 x 2.5''
	Cable Management Tray: 1 Storage Bay: 1 x 3.5'' / 2 x 2.5''
	Storage Bay Included: 4x
PSU Support	ATX
Dimensions	541mm x 259.5mm x 547mm
Volume	17.84kg
Fan PWM Repeater
Fan Ports	2 x PWM repeaters, 12 ports total
Location	1 x Cable Management Tray
Location	1 x PSU Shroud
Fan Connectors	6 ports per repeater x 4-pin PWM
Fan Connectors	(Connect your primary fan to the white port to control PWM signal. All other ports mirror the white port's signal.)
Fan Rated Voltage	12V
Fan Safety Current	Up to 2.6A across 6 ports
Power Connector	1 x SATA Power
Power Safety Current	1 x SATA connector power input, 12V → 2.6A (max)
Pre-Installed Fans
Top	N/A
Right	N/A
Bottom	N/A
Rear	N/A
Fan Support
Top	3x 120mm / 3x 140mm
Right	3x 120mm / 3x 140mm
Bottom	3x 120mm / 3x 140mm
Rear	2x 120mm / 2x 140mm
Rear	Thickness Up to 30mm
Radiator Support
Top	280mm / 360mm / 420mm (Thickness: 65 mm, not overlapping with RAM)
Right	280mm / 360mm / 420mm (Thickness: 60 mm w/ GPU >317mm, 80 mm w/ top AIO)
Bottom	280mm / 360mm / 420mm (Thickness: 120 mm)
Clearance
CPU Cooler Height Limitation	Up to 185 mm
CPU Cooler Height Limitation	Liquid cooling recommended.
PSU Length Limitation	Up to 220mm (Clearance - 290mm)
GPU Clearence	Length: Up to 480mm
	Width: Up to 195 mm
	GPU width support depends on CPU cooler size. CPU center to graphics card PCIe edge connector: ~199mm (varies by motherboard). Liquid cooling recommended.
RAM Clearance	If the fan and radiator thickness is greater than 65mm: 420mm - 32mm / 360mm - 43mm
General
Dust Filters	Bottom, Top, Right & Rear Bottom
Internal Display Support
VESA Mounting	75mm x 75mm
VESA Mounting	100mm x 100mm
Display Size	14" (Max)
Location	Front Right Pillar
Warranty Information
Warranty	2 Year Warranty
