Gigabyte B650M GAMING WIFI6E AMD B650 Ryzen Socket AM5 Micro-ATX Desktop Motherboard

More Views

Please note:
Images are for illustrative purposes only.

Gigabyte B650M GAMING WIFI6E AMD B650 Ryzen Socket AM5 Micro-ATX Desktop Motherboard

Customer's Choice

for AMD B650 Micro ATX Motherboards

Product ID: 51683

✅ Please note: There are optional configurations available below. Simply click on an option to include it with your purchase.

WiFi & Bluetooth Adapter (Optional):
ASUS WiFi 7 Tri-Band PCIe Wireless Adapter

R 549.00
- View

Stock Coming Soon

ETA: 24 April 2026 (Pre-Order Now to Reserve Stock!)

Be the first to review this product

- Micro-ATX Form Factor
- AMD B650 Chipset
- Socket AM5 Supports AMD Ryzen 7000, 8000, 9000 Series Processors
- 2x DDR5 DIMM Slots, Supports Up To 128GB (2x64GB)
- Supports Up to DDR5-6400 (OC)
- Supports AMD EXPO DDR5 Modules
- Supports Intel XMP 3.0 Modules
- 1x PCIe 4.0 x16 Slot
- 1x PCIe 3.0 x1 Slot
- 1x M.2 2580/2280 PCIe 4.0 x4 NVMe SSD Slot
- 4x SATA 6Gbps Ports
- 2x USB 5Gbps Type-A Ports
- 4x USB 2.0 Ports
- 1x HDMI 2.1 (TMDS) Port
- 1x VGA D-Sub
- 1x PS/2 Combo Port (Keyboard, Mouse)
- 3x 3.5mm Audio Jacks
- Realtek 2.5 Gigabit Ethernet RJ-45 LAN
- Realtek WiFi 6E Tri-Band Adapter, Bluetooth 5.3
- Realtek High Definition Audio CODEC
- Gigabyte Q-Flash Plus BIOS Flashback
- Gigabyte RGB Fusion Software
- Gigabyte Control Center Utility
- Supports Windows 11 64-bit
- 3 Year Warranty

159 Products

Please note: pricing visible is already subject to a 2% discount applicable only to EFT payments.

R3,349.00

R2,599.00

Save: R 750!

Qty:

Add to Wishlist

Product Description
Additional Information
Reviews (0)

Product Description

SPECIFICATIONS
Brand	Gigabyte
Series	GAMING Series
Model	B650M GAMING WIFI6E
CPU Support	AMD Socket AM5 for AMD Ryzen 7000, 8000, 9000 Series Desktop Processors
Chipset	AMD B650
Memory Support
AMD Ryzen 7000 Series	Support for DDR5 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s memory modules
	2x DDR5 DIMM sockets supporting up to 128 GB (64 GB single DIMM capacity) of system memory
	Dual channel memory architecture
	Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
	Support for AMD EXtended Profiles for Overclocking (AMD EXPO) and Extreme Memory Profile (XMP) memory modules
Video
VGA	1x VGA D-Sub port, supporting a maximum resolution of 1920x1200 @ 60 Hz
HDMI	1x HDMI 2.1 TMDS port, supporting a maximum resolution of 4096x2160 @ 60Hz, Support for HDMI 2.1 version and HDCP 2.3, Support native HDMI 2.1 TMDS
HDMI	Integrated Radeon graphics required. Actual support may vary by CPU.
Expansion Slots
CPU Direct	1x PCIe 4.0 x16 Physical, x16 Electrical Slot
AMD B650 Chipset	1 x PCIe 3.0 x1 Physical, x1 Electrical Slot
AMD B650 Chipset	Supports NVMe SSD as boot disk
Storage
CPU Direct	1x M.2 connector, integrated in the CPU, supporting Socket 3, M key, type 2580/2280 SSDs (M2A_CPU)
AMD B650 Chipset	4 x SATA 6Gbps connectors
Storage Configurations	RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
	RAID 0, RAID 1, and RAID 10 support for SATA storage devices
	M2A_CPU with Ryzen 8000 Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
	M2A_CPU with Ryzen 8000 Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs
Networking
LAN	Realtek 2.5 Gigabit LAN 10/100/1000/2500Mbps
WiFi	Realtek RTL8852CE WiFi 6E 2x2 MIMO Tri-Band Adapter
Bluetooth	Bluetooth 5.3
Audio
Codec	Realtek High-Definition Audio Codec
Codec	Support for 7.1 Surround with front-panel jack retasking
Connectivity
Ports	2x USB 5Gbps Type-A Ports
	4x USB 2.0 Ports
	1x HDMI 2.1 (TMDS) Port
	1x VGA D-Sub
	1x PS/2 Combo Port (Keyboard, Mouse)
	3x 3.5mm Audio Jacks
	1x Realtek 2.5 Gigabit Ethernet RJ-45 LAN
Buttons	1x Q-Flash Plus button
General
Internal Connectors	1x 24-pin ATX main power connector
	1x 8-pin ATX 12V power connector
	1x CPU fan header
	2x system fan headers
	2x addressable LED strip headers
	1x RGB LED strip header
	1x M.2 Socket 3 connector
	4x SATA 6Gb/s connectors
	1x front panel header
	1x front panel audio header
	1x USB 3.2 Gen 1 header
	2x USB 2.0/1.1 headers
	1x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)
	1x Clear CMOS jumper
I/O Controller	iTE I/O Controller Chip
LED Displays	N/A
BIOS	1x 256 Mbit flash
	Use of licensed AMI UEFI BIOS
	PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor	Micro ATX Form Factor; 240 x 225mm
Operating System Support	Windows 11 64-bit
Warranty Information
Warranty	3 Year Warranty
